Kapsül Dolum Makinesi Boyut Değiştirme Parçaları Nasıl Temizlenir ve Kurulur

Please install the machine according to the video below step by step:

00:01: 1. Install intermediate ring

00:05: 2. Install metering disc washer

00:20: 3. Install copper spacing ring

00:25: 4. Install powder blocking piece

00:35: 5. Install metering panel

00:50: 6. Install powder blocking ring or metering panel

01:15: 6. Install powder blocking ring

02:05: 7. Install filling base

02:45: 8. Install filling rod

02:55: 9. Align and fix the position of filling rod and metering panel

03:15: 9. Install the remaining 5 filling rod modules

03:30: 9. Filling rod position is defined according to the scale

03:55: 10: Install the screw rod to fix the filling rod

04:30: 11. Install the filling screw rod coat

04:50: 12. Install capsule pushing port (discharge port)

05:40: 13. Install upper and lower modules and then calibrate

06:35: 13. Install the remaining 11 sets of modules in turn

07:10: 14. Install capsule locking device

Learn&Buy a capsule filling machine, or learn more about this machine

Technical Document/Installation And Debugging/Routing Shooting And Solution/ Please Contact Us.

Product Description

The machine, a automatic hard capsule filling equipment, operates intermittently and fills capsules with a metering plate of holes. The machine after optimization, considering features of traditional Chinese medicine and requirements of GMP, acquires features of compact structure, small model, low noise, accurate filling volume, complete functions and stable operation. It can also poke, separate, fill and lock capsules, clean wastes, output end products, and clean modules at the same time. For these reasons, this hard capsule filling machine is the ideal equipment for producers of drug, health care products, etc.

Main Features：

1.It has been improved the inner design turret, and imports beeline bearings for each machine from Japan directly, so that it can be sure to get a longer usage-life and precision of machine.

2.The working station cam runs under the good lubricating condition, and maintains the inner lubrication of cam slot to a full extent, increasing the pressure pulverization oil pump, thus extends the operation life of the spare parts.

3.It is controlled by the computer, has a step less timing with the frequency-conversion, the numeral showing makes an easy operation and clear appearance.

4.The multi-bore dosing brings a precision dosage (it is controlled around ±3.5%); The capsule qualified rate is higher than 99%.It can be filled with the Chinese traditional medicine and the Western medicine.

5.It has a protector equipment for the operator and the machine. It has automatic pause equipment when it is lack of the material. It has a steady and safe working, therefore it is the best choice for the hard capsule factories.

6.Additional function of blowing and suction of mould, which ensures the clean and no dust in the holes.
